Set up DNC scrubbing in VICIdial: internal lists and DNC.com

01 / 08

Separate internal filtering from external scrubbing

Fast answer: VICIdial has two different suppression mechanisms, and mixing them up is the most common configuration mistake. An internal do-not-call (DNC) list lives in your own database and is enforced only if the campaign is configured to check it. The optional DNC.com integration is a paid third-party service that batch-scrubs a list of leads after they are loaded, plus a separate real-time check for inbound calls landing on a DID. Neither exists automatically just because the tables and scripts ship with the install.

This is configuration guidance, not legal advice, and it does not establish that any call is lawful. The Telephone Consumer Protection Act (TCPA) is United States federal law; state, provincial, and other countries' do-not-call and telemarketing rules differ and can be stricter. For the legal-boundary and carrier-signaling material — what a DNC check or STIR/SHAKEN attestation does and does not prove, and how far a technical control actually reaches — see the companion article “VICIdial DNC and STIR/SHAKEN: controls, limits and legal review”; this guide is the hands-on counterpart and does not repeat that legal-review discussion.

In plain language: a lead is one contact record, a phone number plus its call history; a list is a named batch of leads you load and dial as a unit; a campaign is one calling project, meaning which leads get dialed, by which agents, under which dialing settings; a DID (direct inward dial number) is a phone number that routes an inbound call into VICIdial; a carrier is the phone company that carries your calls to the public telephone network; a disposition is the outcome code an agent saves after a call, such as SALE or DNC; a hopper is the queue of leads VICIdial has already decided are eligible to dial next.

• Name the jurisdiction (TCPA plus any state, provincial, or other country rule) that applies to this campaign before you configure anything.
• Decide whether you need system-wide suppression, campaign-only suppression, or both.
• Confirm whether DNC.com is even in use; it requires its own paid account and is entirely optional.

02 / 08

Step 1 — Load and manage the internal DNC list

VICIdial keeps a system-wide internal list in the vicidial_dnc table, one row per phone number, checked across every campaign that turns the check on. A separate table, vicidial_campaign_dnc, pairs a phone number with one campaign_id, so a number can be blocked only for a single campaign without ever touching the system-wide list.

Load and remove entries through Lists → the DNC add/delete screen, or through the add_dnc_phone and delete_dnc_phone Non-Agent API functions. Do not write to either table directly: both supported paths write a matching row to vicidial_dnc_log, which is what lets you prove later who suppressed a number and when.

The admin screen accepts more than one campaign at a time. SYSTEM_INTERNAL targets the global list; ALL_CAMPAIGNS, ALL_ACTIVE_CAMPAIGNS, ALL_DNC_CAMPAIGNS, and ALL_ACTIVE_DNC_CAMPAIGNS apply the same add or delete across every campaign that matches that description, which is convenient but also the fastest way to touch far more campaigns than you intended. Read the target value twice before submitting a delete.

Removing a number is the riskier direction of the two. The delete_from_dnc permission on a user account is what actually allows a deletion to go through; review who holds that permission the same way you would review any other destructive-action grant.

• Confirm whether the number belongs on the system-wide list, a single campaign's list, or both.
• Use the admin screen or the API, never a direct table write.
• Review delete_from_dnc grants on a regular schedule.

SHOW CREATE TABLE vicidial_dnc;SHOW CREATE TABLE vicidial_campaign_dnc;SELECT COUNT(*) AS system_dnc_rows FROM vicidial_dnc;SELECT COUNT(*) AS campaign_dnc_rows FROM vicidial_campaign_dnc WHERE campaign_id='<CAMPAIGN_ID>';

03 / 08

Step 2 — Choose system-level vs. campaign-level scope

Two campaign settings decide whether either list is even consulted: use_internal_dnc controls the system-wide vicidial_dnc table, and use_campaign_dnc controls that campaign's own vicidial_campaign_dnc entries. Each accepts Y, N, or AREACODE — AREACODE blocks every number sharing the same area code as a listed entry, not just an exact match, which is useful when an entire region has opted out of a campaign rather than one number.

A third setting, use_other_campaign_dnc, lets one campaign also honor a second, named campaign's list without merging or duplicating the underlying rows. A fourth, callback_dnc, decides whether a scheduled callback re-checks DNC before it redials; leaving it DISABLED means a callback can still reach a number that was added to DNC after the callback was scheduled.

This is the gotcha that catches most new installs: a number sitting in vicidial_dnc or vicidial_campaign_dnc proves nothing about enforcement on its own. If the campaign's flag is N, the row is simply never read. Always check the list and the flag together, never one on its own.

• Read use_internal_dnc and use_campaign_dnc together with the DNC tables, not instead of them.
• Decide the AREACODE behavior deliberately; it blocks an entire area code, not one number.
• Set callback_dnc to ENABLED unless you have a specific, documented reason not to.

SELECT campaign_id, use_internal_dnc, use_campaign_dnc, use_other_campaign_dnc, callback_dncFROM vicidial_campaignsWHERE campaign_id='<CAMPAIGN_ID>';

04 / 08

Step 3 — Configure the optional DNC.com integration

DNC.com is a separate paid service, configured through a settings container with the ID DNCDOTCOM, a row in vicidial_settings_containers. That container holds your DNC.com API login, which list IDs to scrub, which statuses to skip, and — this is the part worth reading twice — a mapping from every one of DNC.com's single-letter result codes to a status you choose in vicidial_list.

The result codes cover more than a plain do-not-call match. C is clean, D is a do-not-call database match, and P is an internal project DNC or do-not-fax match. W and Y flag a wireless or VoIP number that is not on any DNC list but still cannot be called from a predictive dialer. E, O, and R describe established-business-relationship (EBR) exemptions — currently valid, overriding an otherwise-DNC number, or expired — while X is a distinct Industry eXemption applied to an otherwise do-not-call number, not an EBR. G and H add a valid EBR on top of a wireless or VoIP number, and that EBR still does not lift the predictive-dialer restriction those numbers carry. Only F, L, and V name a state that bans even a manually dialed wireless call — L alone, F combined with a valid EBR, and V combined with an EBR that overrides an otherwise-DNC number. I and M flag an invalid or malformed number, B flags a number blocked by area-code coverage or campaign configuration, S flags a disconnected-number match, and T flags a costlier Tier-C carrier route rather than any data-quality problem. Map each code to its own status so a report can tell them apart later.

Outbound scrubbing runs strictly in batch: the AST_DNCcom_filter.pl script scrubs the list IDs you name, typically from cron, and is documented as something you should run after hours or only against inactive lists — it does not look up a number at the moment you dial it. Inbound filtering is the opposite: set a DID's Filter Inbound Number option to URL, point its Filter URL at DNCcom_inbound_filter.php, and every inbound call to that DID is checked in real time against the USADNC, PROJDNC, LITIGATOR, and INVALID categories you choose. Set that DID's Clean CID Number option to R10 so ten-digit North American numbers are looked up consistently.

• Confirm which list IDs are actually included in VICI_LISTS before the first run.
• Set VICI_STATUS_SKIP to exclude already-worked statuses such as SALE, so a rescrub cannot overwrite a completed disposition.
• Schedule the outbound batch job on inactive lists or after hours, since it is documented as batch-only.

#!/usr/bin/env bashset -euo pipefailLIST_RANGE='<LIST_ID_A>-<LIST_ID_B>'/usr/share/astguiclient/AST_DNCcom_filter.pl --lists=$LIST_RANGE# Inbound DID Filter Inbound Number = URL; Filter URL points at the same account, e.g.:# https://203.0.113.10/vicidial/DNCcom_inbound_filter.php?phone=--A--phone_number--B--

05 / 08

Where a lead actually gets blocked in the call path

Suppression is checked at more than one point, and knowing which one fired matters when a call gets through that should not have. A batch worker, AST_DB_DNC_filter.pl, can pre-scrub a freshly loaded list against the system and campaign DNC tables and flip a matching lead's status to DNCL for a system match or DNCC for a campaign match, before that lead is ever eligible to dial.

Hopper fill is the next gate: AST_VDhopper.pl applies status, list, time, DNC, and rank rules when it selects leads into vicidial_hopper, the queue of leads eligible to dial next. A lead that never enters the hopper cannot be dialed by that campaign, regardless of what an agent sees on screen.

Manual, ratio, and adaptive dialing all draw from the same hopper, so they share that check. A scheduled callback is the exception: it only re-checks DNC before redialing when the campaign's callback_dnc setting is ENABLED, so a callback created before a number was added to DNC can still go out if that setting is off. Inbound calls take a completely separate path, evaluated per call rather than per lead, through the inbound DNC/CID lookup AGI or the DNC.com inbound filter on the receiving DID.

The DNC disposition status itself — the one an agent or an API sets after a live contact asks to be removed — is a different thing again. That status records a request going forward; it does not retroactively prove the earlier call should have been blocked.

• Trace a suspect call through the batch pre-scrub, hopper fill, and callback flag in that order.
• Check inbound DIDs separately; they do not share the outbound hopper path.
• Do not treat a DNC disposition on one call record as proof the number was suppressed beforehand.

06 / 08

Prove a specific number is actually suppressed

A claim that a number 'is on the DNC list' is not enough on its own. Read three things together for the exact number and campaign in question: whether the number is present in the system or campaign table, whether that campaign's flag actually consults that table, and what status the lead currently carries in vicidial_list.

The read-only session below runs all three checks for one number using the placeholder <PHONE_NUMBER> in place of a real subscriber's number. Run the same three queries against your own test number before you trust any dashboard count.

#!/usr/bin/env bashset -euo pipefailREADONLY_CNF=/etc/vicidial-readonly.cnfPHONE='<PHONE_NUMBER>'mysql --defaults-extra-file=$READONLY_CNF -e "SELECT phone_number FROM vicidial_dnc WHERE phone_number='$PHONE';"mysql --defaults-extra-file=$READONLY_CNF -e "SELECT phone_number, campaign_id FROM vicidial_campaign_dnc WHERE phone_number='$PHONE';"mysql --defaults-extra-file=$READONLY_CNF -e "SELECT lead_id, list_id, status FROM vicidial_list WHERE phone_number='$PHONE';"

07 / 08

Keep an auditable record of every suppression

vicidial_dnc_log records every add and delete against either DNC table with the acting user, an add-or-delete action, a campaign_id (or -SYSINT- for the system list), and a timestamp. Read it by phone number to answer who suppressed this number, when, and through which list.

The admin screen additionally writes a matching vicidial_admin_log row with the section, the exact action, and the SQL that ran, which is useful when you need to show an administrative action rather than just the resulting row. For DNC.com, vicidial_dnccom_filter_log records each outbound batch result per lead (old status, new status, and the raw response), and vicidial_dnccom_scrub_log records each inbound real-time result per phone number with separate invalid, DNC, project-DNC, and litigator flags.

Together these four sources are the record you keep: the two DNC tables say what is currently suppressed, and these logs say how it got that way. Retain them at least as long as your compliance owner requires, and never let a bulk cleanup delete log rows just to shrink a table.

SELECT campaign_id, action, action_date, userFROM vicidial_dnc_logWHERE phone_number='<PHONE_NUMBER>'ORDER BY action_date DESCLIMIT 1000;

08 / 08

Troubleshoot a bad scrub, stop it, and roll back safely

Three symptoms cover most real incidents. A huge, unexpected share of a list changing to one DNC.com status overnight usually means VICI_STATUS_SKIP did not exclude an active work status the way you intended. A campaign that keeps dialing a number you added to vicidial_dnc usually means use_internal_dnc or use_campaign_dnc is N on that specific campaign, not that the add failed. Inbound calls that are not being screened at all usually mean a DID's Filter Inbound Number was left DISABLED instead of set to URL.

If a batch run mis-set statuses, stop the cron job first, then use vicidial_dnccom_filter_log to find exactly which lead_id and list_id rows changed and what their old_status was. Restore only those rows through the admin lead screen or the update_lead API function, never a bulk update statement.

If you need to reverse an internal DNC add, use the Admin delete screen or the delete_dnc_phone API function, gated by the delete_from_dnc permission from step 1, rather than a direct delete against the table. That path writes the same audit row that later proves the reversal happened. Rollback here means a documented reversal through the same supported interface that made the original change, not a manual SQL fix applied under pressure.

Whatever you changed, re-run the proof from the earlier section against the exact number and campaign involved before you consider the incident closed. A fix you cannot re-verify is not a fix yet.

• Stop the batch job before investigating, not after.
• Restore only the specific rows a log identifies, never with a bulk statement.
• Close the incident only after re-running the suppression proof on the affected number.
